T4E Under cabinet LED lighting
T4E spec sheet
Download Product Specs
Specifications & Features
T4E Series is our premium diffusion no hot spot work station fixture just under 1” in height. High 90+ CRI provides excellent lighting effects.
Cool to touch operation and virtually no heat, no UV or forward heat.
Four sizes to choose from, rear raceway cover and 1/2 inch knockout along back and top of fixture for easy access.
Tech Specs
_____________________________________________________
LED Performance:
LED: 5630
SDCM: 3 Step Macadam Elipse
CCT: 3000K, 4000K
CRI: >90 Typically 95
LIFE: 70% of initial lumens after 50,000 hrs
Warranty: 5 Year Limited Fixture Warranty
_____________________________________________________
Dimensions:
H = 0.96" W = 3.78" L = 8",16",24",32"
_____________________________________________________
Technical Specifications:
- 4 difference sizes Premium Diffusion dimmable fixtures
- 5.3~17.3 W dimmable under-cabinet fixtures
- 250 ~ 1100 lumens output
- Hardwired and portable listing
- Linkable up to 400 watt
- Canada / USA ETL listing
_____________________________________________________
Included:
- Complete ready to install Premium Diffusion fixture
- Captive mounting screw already on fixture
- 1⁄2" Die-Cast metallic cable clamp
- Direct end-to-end connector
_____________________________________________________
Finishes:
WH BZ
_____________________________________________________
Accessories:
JBL
JBL-OCS-120V (T4E 120V)
JBL-OCS-277V (T4E 277V)
LPC1800
LPD1800
LJP0150
LJP0300
LJP1800
_____________________________________________________
Ordering Codes:
T4E 120V
- 8” order code length =T4E8XX930
- 16” order code length =T4E16XX930
- 24” order code length =T4E24XX930
- 32” order code length =T4E32XX930
T4E 277V
- 8" order code length =T4E8XX930-277V
- 16" order code length =T4E16XX930-277V
- 24" order code length =T4E24XX930-277V
- 32" order code length =T4E32XX930-277V
