DA-A35
DA-A35 series LED recessed down light is a constant current design can use with 350mA 500mA or 700mA driver.
Heat sink design to use best with 500mA driver.
Using CoB chips available with 3000K, 4000K & 5000K.
Dimmable driver available by others.
Max rated output: 350mA is 500 lumens, 500mA is 700 lumen. 700mA is 900 lumens. 80+ CRI standard (Optional 90+ CRI is available).
ETL listed for USA & Canada
Tech Specs
_____________________________________________________
LED Performance:
LED: CoB
CCT: 3000K (WW), 4000K (NW), 5000K (CW)
CRI: >80 Typically 83 (Optional 90+ CRI is available)
LIFE: 70% of initial lumens after 50,000 hrs
Warranty: 5 Year Limited Fixture Warranty
_____________________________________________________
Dimensions:
DA-A35C
Diameter = 3" Depth = 2.65"
DA-A35D
Diameter = 3.25" Depth = 1.65"
DA-A35N
Diameter = 3.25" Depth = 1.4"
_____________________________________________________
Technical Specifications:
- Typical 7.5W 500mA
- Typical 700 lumens @ 500mA
- High Output CoB LED
- Front glass lens & user changeable reflector.
- Specify Driver separately
- 80+ or 90 + CRI
_____________________________________________________
Included:
- Included: 25 degrees reflector, 40 degrees reflector available
_____________________________________________________
Finishes:
WU BZ SY BK
_____________________________________________________
Accessories:
DA-A35D - Gimbal fixture 350mA~700mA
DA-A35C - Deep Cone fixture 350~700mA
DA-A35N - Down Light low profile 350~700mA
IP-Cover - Clear IP-cover lens for D & N models
LSC9W500P - 120~277V 9W 500mA driver (UL)
DA-A35-R40 - 40 degree reflector for all models
